ENC-2800HL – Panel Cooler Side-Mounting Freon-Gas Kapasitas Tinggi

ENC-2800HL adalah unit pendingin panel kontrol tipe side-mounting dengan kapasitas sekitar 2.500–2.800 W, menggunakan refrigeran R134a. Cocok untuk penggunaan suhu tinggi, mampu bekerja pada temperatur ambient hingga 70 °C dan setting internal juga sampai 70 °C. Dirancang dengan proteksi debu dan cipratan (IP54 internal sirkulasi), dimensi H1.455 × W480 × D260 mm, berat 72 kg.

Dilengkapi output alarm eksternal dan opsi pengaturan suhu yang luas serta rating voltase tiga fase 200V AC.

Deskripsi

Spesifikasi ENC-2800HL

Mounting type	Side-mounting
Cooling capacity(W)	2500/2800
Setting temperature range(℃)	30 to 70
Ambient Temperature(℃)	30 to 70
Ambient Humidity(%RH)	10～85（～45℃）、10～45（～55℃）、10～30（～65℃）、10～20（～70℃）
Dimensions(mm)	H1455×W480×D260
Weight(kg)	72
Coating Color	Munsell 5Y 7/1 Equivalent color of light beige
Rated voltage(V)	Three-phase 200V AC
Current consumption : Rating(A)	5.0/5.2 (When the ambient temperature of 35 ° C)
Current consumption : Max(A)	6.9/7.3 (When the external temperature is 70 ° C)
Starting Current(A)	30
Power consumption : Rating(W)	1000/1190 (When the external temperature is 35 ° C)
Power consumption : Max(W)	1800/2150 (When the external temperature is 70 ° C)
Noise Resistance	1.5 kV (based on 50 ns, 1 μs, pulse width common, normal mode, noise simulator)
Vibration resistance	5Hz frequency 20mm total amplitude
Dustproof and splashproof protection grade	Equivalent to IP54 (internal circulation route)
Refrigerant / Amount(g)	R134a 933g
Noise (dB (A))	Approx. 67/72
